* Refer to www.asus.com for CPU support list.

6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800MHz, Un-buffered Memory*”

Dual Channel Memory Architecture

Supports AMD® EXTended Profiles for Overclocking (EXPO™)

OptiMem II

* Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list.

* Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function

2 x  USB4® ports support USB Type-C® display outputs**

*Supports 4K@60Hz as specified in HDMI 2.1.

**VGA resolution support depends on processors’ or graphic cards’ resolution.

2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 mode(s)*

AMD X670 Chipset

1 x PCIe 4.0 x1 slots

* When the PCIe 5.0 M.2 card is installed on the PCIEX16_2 slot, PCIEX16_1 will run x8 only.

AMD Ryzen™ 7000 Series Desktop Processors

M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)

M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)

PCIe 5.0 M.2 slot (Key M) via PCIe 5.0 M.2 card, type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)**

AMD X670 Chipset

M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 )

M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 )

6 x SATA 6Gb/s ports

*AMD RAID Xpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10.

**Performance may vary depending on the SSD’s firmware version and the system hardware & system configuration, for more information refer to www.asus.com for device support list.

ASUS LANGuard

2×2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)

Supports 2.4/5/6GHz frequency band*

Bluetooth v5.2

* WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later.

– Impedance sense for front and rear headphone outputs

– Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

– High quality 120 dB SNR stereo playback output and 113 dB SNR recording input

– Supports up to 32-Bit/384 kHz playback”

Audio Features

– SupremeFX Shielding Technology

– ESS® ES9218 QUAD DAC

– Gold-plated audio jacks

– Rear optical S/PDIF out port

– Premium audio capacitors

– Audio cover

2 x USB4® ports with Intel® JHL8540 USB4® controller (2 x USB Type-C®)

1 x USB 3.2 Gen 2×2 port(s) (1 x USB Type-C®)

9 x USB 3.2 Gen 2 port(s) (8 x Type-A + 1 x USB Type-C®)

Front USB (Total 11 ports)

1 x USB 3.2 Gen 2×2 connector (supports USB Type-C® with up to 60W PD/QC4+)*

2 x USB 3.2 Gen 1 headers) support additional 4 USB 3.2 Gen 1 ports

3 x USB 2.0 headers support additional 6 USB 2.0 ports

*To support 60W, please install the power cable to the 6-pin PCIe Graphics Card connector or else only 27W can be supported.

– FlexKey button

– ReTry button

– Start button

Extreme Engine Digi+

– 10K Black Metallic Capacitors

– MicroFine Alloy Choke

ASUS Q-Design

– M.2 Q-Latch

– PCIe Slot Q-Release

– Q-Code

– Q-Connector

– Q-DIMM

– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])

– Q-Slot

ASUS Thermal Solution

– M.2 heatsink backplate

– M.2 heatsink

– VRM heatsink design

ASUS EZ DIY

– BIOS FlashBack™ button

– Clear CMOS button

– ProCool II

– Pre-mounted I/O shield

– SafeSlot

– SafeDIMM

Aura Sync

– Aura RGB header

– Addressable Gen 2 headers

Front Panel USB 3.2 Gen 2×2 with Quick Charge 4+ Support

– Support: up to 60W charging*

– Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A

– Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS

* To support 60W, please install the power cable to 6-pin PCIe Graphics Card connector or can only support 27W

– GameFirst VI

– ROG CPU-Z

– Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion

– Sonic Radar III

– DTS® Sound Unbound

– BullGuard Internet Security (1-year full version)

ASUS Exclusive Software

Armoury Crate

– AIDA64 Extreme (1 year full version)

– Aura Creator

– Aura Sync

– Fan Xpert 4 with AI Cooling II

– Power Saving

– Polymo Lighting

– Two-Way AI Noise Cancellation

AI Suite 3

TPU

DIGI+ Power Control

Turbo app

PC Cleaner

MyAsus

WinRAR

UEFI BIOS

ASUS EZ DIY

– ASUS CrashFree BIOS 3

– ASUS EZ Flash 3

– ASUS UEFI BIOS EZ Mode

1 x USB 3.2 Gen 2×2 port (1 x USB Type-C®)

9 x USB 3.2 Gen 2 ports  (8 x Type-A + 1 x Type-C®)

1 x HDMI® port

1 x Wi-Fi Module

1 x Intel® 2.5Gb Ethernet

5 x Gold-plated audio jacks

1 x Optical S/PDIF out port

1 x BIOS FlashBack™  button

1 x Clear CMOS button

1 x 4-pin CPU Fan header

1 x 4-pin CPU OPT Fan header

1 x 4-pin AIO Pump header

4 x 4-pin Chassis Fan headers

1 x W_PUMP+ header

1 x 2-pin Water In header

1 x 2-pin Water Out header

1 x 3-pin Water Flow header

Power related

1 x 24-pin Main Power connector

2 x 8-pin +12V Power connector

1 x 6-pin  PCIe Power connector

Storage related

4 x M.2 slots (Key M)

6 x SATA 6Gb/s ports

USB

1 x USB 3.2 Gen 2×2 connector (supports USB Type-C®)

2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports

3 x USB 2.0 headers support additional 6 USB 2.0 ports

Miscellaneous

3 x Addressable Gen 2 headers

1 x Alteration Mode Switch

1 x Aura RGB header

1 x FlexKey button

1 x Front Panel Audio header (AAFP)

1 x ReTry button

1 x Start button

1 x 10-1 pin System Panel header

1 x Thermal Sensor header

1 x ARGB RGB extension cable

1 x RGB extension cable

4 x SATA 6Gb/s cables

PCIe 5.0 M.2 Card with Heatsink

1 x PCIe 5.0 M.2 Card with heatsink

1 x M.2 screw package for PCIe 5.0 M.2 Card

Additional Cooling Kit

1 x Thermal pad for M.2

Miscellaneous

1 x ASUS Wi-Fi moving antennas

3 x Rubber Packages for M.2 backplate

1 x Q-connector

1 x M.2 Q-Latch package

3 x M.2 Q-Latch packages for M.2 backplate

1 x ROG Graphics card holder

1 x ROG key chain

1 x ROG stickers

1 x ROG thank you card

Installation Media

1 x USB drive with utilities and drivers

Documentation

1 x User guide

12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
