MSI PRO H610M-G WIFI

12,711.02

Brand:
MSI
  • Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors for LGA 1700 socket
  • Supports DDR4 Memory, up to 3200(MAX) MHz
  • Core Boost : With premium layout and digital power design to support more cores and provide better performance
  • Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility
  • Lightning Fast Experience: PCIe 4.0
  • Audio Boost: Reward your ears with studio grade sound quality
  • Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.
  • Wireless and Bluetooth: Intel® Wi-Fi 5, Bluetooth 4.2

Available on backorder

+
  •  Size Guide

    Size Guide

    Size Chest Waist Hips
    XS 34 28 34
    S 36 30 36
    M 38 32 38
    L 40 34 40
    XL 42 36 42
    2XL 44 38 44

    All measurements are in INCHES

    and may vary a half inch in either direction.

    Size Chest Waist Hips
    2XS 32 26 32
    XS 34 28 34
    S 36 30 36
    M 38 32 38
    L 40 34 40
    XL 42 36 42

    All measurements are in INCHES

    and may vary a half inch in either direction.

    Size Chest Waist Hips
    XS 34 28 34
    S 36 30 36
    M 38 32 38
    L 40 34 40
    XL 42 36 42
    2XL 44 38 44

    All measurements are in INCHES

    and may vary a half inch in either direction.

  •  Delivery & Return
    Goods once sold will not be taken back or exchanged. Once invoice made cannot be modified or cancelled for any reasons thereof. The item is tested for physical damage at the point of sale and the company is not liable for the physical damage of item any more. It is also the duty of the buyer to immediately check at the counter physical condition of the purchased goods. All goods are consigned at buyer’s risk and the company is not responsible for any loss, damage or pilferage in transit. Our responsibility ceases the moment goods leaves our warehouse.

    Physical damage / Mishandling of product/Tampering of warranty stickers –do not cover warranty. All Products sold by us require technically qualified PC hardware engineer for installation.

    Price, specifications and terms of offers are subject to change without notice. PCB WORLD TECH is not responsible for typographical and/or photographical errors. Retail products are accompanied by the original manufacturer warranty. PCB WORLD TECH does not offer any technical support or sales advice. Physical damage to any product purchased at PCB WORLD TECH will effectively void warranty coverage. Improper Installation of CPU fans and/or improper clocking may cause CPUs to chip. CPUs that are chipped, burnt or have bent pins are considered physically damaged and cannot be returned for replacement. Physical damage includes but is not limited to improper handling and/or any other type of damage sustained by irregular usage. As a result, PCB WORLD TECH will return any physically damaged Products back to the customer at the customer’s expense. You can expect your order to be processed within approximately 24-48 hours, provided the items are in stock and there are no problems with payment verification. Although PCB WORLD TECH does not guarantee same day-shipping we shall strive to do so wherever possible. Orders are not processed on weekends and holidays.
  ... people are viewing this right now

  Share
Guaranteed Safe CheckoutTrust

MSI H610M-G WIFI

Specifications:

Processor Processor socket LGA1700
Chipset Intel® H610 Chipset
Memory 2x DDR4 memory slots, support up to 64GB

Supports 1R 2133/ 2666/ 2933/ 3200 MHz (by JEDEC & POR)

Supports  Dual-Channel mode

Supports non-ECC, un-buffered memory

Expansion Slot
  • 1x PCIe x16 slot (From CPU)
  • Supports up to PCIe 4.0 x16
  • 1x PCIe x1 slot
  • Supports PCIe 3.0 x1
Wireless LAN & Bluetooth® Intel® Wi-Fi 5

  • Supports 802.11 a/b/g/n/ac, MU-MIMO Rx, 2.4GHz/ 5GHz up to 433 Mbps
  • Supports Bluetooth® 4.2
Onboard Graphics
  • 1x HDMI™ 2.1 with HDR port, supports a maximum resolution of 4K 60Hz
  • 1x VGA port, supports a maximum resolution of 2048×1536 50Hz, 2048×1280 60Hz, 1920×1200 60Hz
  • 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz
SATA Ports 4x SATA 6Gb/s ports
M.2 SSD Slot
  • 1x M.2 slot (Key M, from chipset)
  • Supports up to PCIe 3.0 x4
  • Supports up to SATA 6Gb/s
  • Supports 2242/ 2260/ 2280 storage devices
  • Supports Intel® Smart Response Technology for Intel Core™ processors
USB Intel® H610 Chipset

  • 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
  • 6x USB 2.0 ports (4 Type-A ports on the back panel(hub-GL850G), 2 ports available through the internal USB 2.0 connector)
Audio Realtek® ALC897 Codec

  • 7.1-Channel High Definition Audio
LAN
  • 1x Intel® I219V 1Gbps LAN controller
Power Connectors
  • 1x 24-pin ATX main power connector
  • 1x 8-pin ATX 12V power connector
Fan Connectors
  • 1x 4-pin CPU fan connector
  • 1x 4-pin system fan connector
System Connectors
  • 1x Front panel audio connector
  • 2x System panel connector
  • s 1x Chassis Intrusion connector
  • 1x TPM module connector
Jumpers
  • 1x Clear CMOS jumper
LED Features
  • 1x 4-pin RGB LED connector
  • 2x 3-pin RAINBOW LED connectors
  • 4x EZ Debug LED
Back panel ports
  • HDMI™
  • VGA
  • DisplayPort
  • Keyboard/Mouse
  • USB 3.2 Gen 1 5Gbps Type-A
  • LAN port
  • Audio connector
  • USB 2.0
Dimensions
  • mATX Form Factor
  • 9.61 x 8.31 in. (24.4 cm x 21.1 cm)
Operating System Support for Windows® 11 64-bit
Warranty 3 Years
Note *** Features, Price, Specifications are subject to change without notice.
